Aspen Silent+ Mini Lime Condensate Pump

Aspen Silent+ Mini Lime Condensate Pump

Aspen Silent+ Mini Lime Condensate Pump — compact, whisper-quiet and energy-efficient condensate pump ideal for air-conditioning systems. It supports up to 46 kW cooling loads, pumps up to 40 L/hour, and operates at just 16 dB(A), making it perfect for quiet environments. Installation is plug-and-play, with flexible left/right mounting and compatibility with most trunking systems. The pump consumes only ~2.1 W, draws very little power, and comes as a complete ready-to-fit kit with hoses and trunking accessories.

Main Features:

• Ultra-quiet operation at as low as 16 dB(A) @ 1 m — nearly silent under normal use.
• High performance: up to 40 L/hour flow rate, with a maximum head of 15 m — efficient condensate removal for large ACs.
• Low power consumption — works at 100-250 VAC, about 2.1 W, using up to 10× less energy than previous generation pumps.
• Easy installation: Plug & Play cable, fits all major trunking systems; no damper or anti-siphon needed.
• Flexible mounting: supports left or right installation, compatible with different ducting/trunking styles — Slimline, Kwik Fix, O-Ducting, S-Ducting, etc.

• 40L/h max. flow15m max. rec. head
• 16dB(A) @ 1m
• Backwards compatible plug & play cable
• Fits all popular trunking systems
• Quick install - no need for damper
• Up to 40L/h flow rate
• 10 x lower power consumption

Main Specifications:

·      Max. flow: 40L/h @ 0m head

·      Max. rec. head: 15 m

·      dB (a): As low as 16 dB(A)*

·      Power supply: 100-250 VAC, 0.18A, 2.1W, 50/60Hz

·      Rated: Continuous

·      Class: II

·      Max. unit output: Up to 46kW / 157000Btu/h

·      Max. water temp: 40oC

·      Inlets: Inlet o/d: Ø16mm

·      Outlets: Outlet o/d: Ø6mm

·      IP Protection: IP24

·      Safety switch: 5.0A N.C. (Normally Closed)

·      Self-priming: ✓

In a Box:

• Silent+ Mini Lime pump (including 1.5m Plug & Play cable)
• 500mm Lime green inlet hose 14mm ID
• 40mm Vinyl breather tube 6mm ID
• Elbow front and back
• 800mm trunking front and back
• Internal trunking sleeve (Slimline system only)
• Gasket (Slimline, S-Ducting and Inoac systems only)
• Ceiling plate
• Drain connector kit
• Fixing kit
• Quick Start Guide
