G60 Series Water Booster Pump

#NSX0XXXXX

Product Description

Flojet G60 Series water boost pump

G601215
PRODUCT FEATURES

Accommodates flow rates up to 4 GPM (15 LPM)
Capable of CO2 inlet pressures up to 90 psi (6.2 bar)
Ultimate performance and reliability with extended service life
Quiet operation
Easy installation with quick disconnect ports

The Flojet G60 Series water boost pump is engineered to provide water boosting for filtration systems, supply carbonators, non-carbonated dispensing valves, carts, coffee machines, hand wash sinks, ice machines, and FCB equipment.

Main Specifications:

SPECIFICATIONS	G60-1215
Pump Drive	CO2 gas, Nitrogen or compressed dry filtered air
Materials of Construction	(wetted parts:) Polypropylene, Santoprene®, EPDM, AISI 303 & 304 Stainless Steel
Displacement US Gallons (litres)	3.2 oz (91ml) per cycle
Operating Pressure	20 - 90 PSI; 1.4 - 6.2 bar max
Operating temperature	34°F to 120°F; 1.1°C to 49°C
Maximum Liquid Inlet Pressure	30 psi; 2.1 bar max
Flow Rate US gallons (litres)	5 GPM (18.9 LPM) - open flow
Dimensions (H x W x D)	5.27 x 3.21 x 4.58 (inches) 133.8 x 81.5 x 116.3 (mm)
Warranty Period	1 year
Approvals	CE, SK, NSF Standard 18
Weight	0.56 (kg) 1.24 (lb)
Product Inlet Fitting	1/2" (9.52mm) Barbed Straight Plastic(Polypropylene)
Product Outlet Fitting	1/2" (9.52mm) Barbed Straight Plastic (Polypropylene)
Gas/Air Inlet Fitting	1/4" (6.35mm) CO2 Shutoff Brass

Click to download : G60 Series Water Booster Pump

Click to download : Flojet G60 Series water boost pump technical drawing

Click to download : CO2 SAFETY BULLETIN

Additional Information

NESPL Code	NSX0XXXXX
Manufacturer Code	G60-1215
HSN Code	----
Manufacturer	FLOJET / XYLEM PUMPS
Voltage	N/A
Model	G60 Series
Power	90 psi (6.2 bar)
Weight	0.56 (kg) 1.24 (lb)
Type	Pump
