N5000 Gas (C02)/Air Driven Pump
(In Stock)

#NSSP001808

Product Description

N5000 Gas (C02)/Air Driven Pump Designed for dispensing Bag-in-Box syrups, juice concentrate (without pulp or particulate), teas, wines, draft beers and liquor. Supplies the following from remote location: four (4) 3.0 oz. valves (Each valve dispenses syrup at 0.5 oz./sec.) or two (2) 4.5 oz. valves (Each valve dispenses syrup at 0.75 oz./sec.) Compact design with quick disconnect fittings for simple, quick installation. Shuts off automatically when bag is empty and restarts when a full bag is connected. High altitude auto shut-off also available. Fully automatic, operates only when beverage is being dispensed. 1/4" barbed, CO 2 exhaust port connection for venting away from confined areas. Maintains constant pressure at the dispensing valve. High suction capability empties the bag down to a minimum residual. Service life up to 40,000 gallons (150,000 L). Power Source CO2 Gas, Nitrogen or Compressed Filtered Air Materials of Construction Celcon M90, Santoprene®,EPDM, 302 or 304 Stainless Steel Spring Temperature Range 34 - 120 (°F) 1.1 - 49 (°C) Displacement 2.5 oz. per cycle Self Priming Up to 10 ft. (3.05 m) Operating Pressure 20 - 80 (psi ) 1.4 - 5.5 (bar) Max. Liquid Inlet Pressure 10 (psi) 0.7 (bar) Flow Rate 4.0 oz/sec (118.3ml/sec) Mean Service Life 40,000 gallons (150,000 litres) Dimensions 13.57 x 15.79 x 6.19 (cms) 5.3/8 H x 6.7/32 W x 2.7/16 D (inches)

Soft Drink Industry

REFRIGERATION-AC

Additional Information

NESPL Code NSSP001808
Manufacturer Code N5000
HSN Code 84138190
Manufacturer Flojet
Voltage N/A
Model N5000-130, N5000-135, N5000-140, N5000-153, N5000-515, N5000-145, N5000-146, N5000-149, N5000-158, N5000-163, N5000-166, N5000-167, N5000-568, N5000-573, N5000-210A
Power CO2 Gas, Nitrogen or Compressed Filtered Air
Weight 0.488 Kg
Type Pump
