Tygon® LCF Tubing

#SGN14

Product Description

Tygon® LCF Tubing

Tygon® LCF is a specialized thermoplastic elastomer (TPE) tubing created by Saint-Gobain Medical to fulfill the stringent demands of the medical sector. Designed for both flexibility and durability, Tygon LCF boasts an exceptionally low coefficient of friction (COF), making it suitable for applications that require smooth, lubricated movement, such as endoscopes and fiber optic cables. In contrast to conventional fluoropolymers, Tygon LCF can endure gamma sterilization without losing its mechanical strength. Whether utilized in tracheal insertion or urinary procedures, Tygon LCF tubing provides a soft, flexible design that may enhance patient comfort—especially in minimally invasive methods like Natural Orifice Transluminal Endoscopic Surgery (N.O.T.E.S.), which accesses the peritoneal cavity through natural openings.

Main Features:

Economical polymer with a low coefficient of friction.
Retains lubricating properties post gamma sterilization, in contrast to PTFE.
Designed for both flexibility and durability.

Main Specifications:

Property	ASTM Method	Value or Rating
Durometer Hardness (Shore A)	D2240	72
Tensile Strength, psi (Mpa)	D412	2710 (18.68)
Ultimate Elongation, %	D412	810
Tear Resistance, lbs-f/in (kN/m)	D1004	270 (.03)
Compression Set Constant Deflection, % @ 158°F (70°C) for 22 hours	D395	17
Specific Gravity	D792	0.90
Maximum Recommended Operating Temperature °F (°C)	N/A	100 (38)
