PLCD2200606MBLK 3/8

#NCPC285

Product Description

PLCD2200606MBLK

3/8" Hose Barb, Valved, In-line Coupling Insert

Main Features:

  • Single thumb latch
  • Latch always in position to accept insert
  • Compact, modular design
  • Independent quick connections

Main Benefits:

  • Minimizes inadvertent latch activation
  • Ensures leak-free operation
  • Fits well in the hand and is easy to wipe down
  • Requires minimal manual dexterity

Main Specifications:

  • Material: ABS
  • Material Finish: White with blue latch
  • Pressure Range: Vacuum to 20 psi, 1.38 bar
  • Mounting Option: Free Floating
  • Sterilization: EtO, e-beam or gamma
  • Temperature Range: 32°F - 120°F (0°C - 48°C)
  • Seal Options: BUNA-N
  • Valve Spring: 316 Stainless Steel
  • Valve Option: Valved
  • Body Type: Insert
  • Bag Qty: 25

COUPLING INSERTS - ABS

TERMINATION

IN-LINE HOSE BARB

TUBING/

THREAD SIZE

3/8" ID

METRIC

EQ.

9.5mm ID

SHUTOFF

PLCD2200606MBLK

A(Height/Diameter)

0.73 (18.5)

B (Total Length)

1.69 (42.9)

*All measurements are in inches (millimetres) unless otherwise noted.



Note: Image is just for ref.

WARNING: Pressure, temperature, chemicals, and operating environment can affect the performance of couplings. It is the customer's responsibility to test the suitability of CPC products in their own application conditions.

Read More

Medical (Core) & Thermal Industry

Additional Information

NESPL Code NCPC285
Manufacturer Code PLCD2200606MBLK
Manufacturer CPC Quick Connect & Disconnect Solutions
Type Quick Fittings
