CPC Quick Connect & Disconnect Solutions PLCD23006 -3/8 Hose Barb Valved Elbow Acetal Coupling Insert NSSP006662

PLCD23006 -3/8 Hose Barb Valved Elbow Acetal Coupling Insert Copy

#NSSP006662 Copy

Product Description

PLCD23006 -3/8 Hose Barb Valved Elbow Acetal Coupling Insert

The CPC PLCD23006 is a valved elbow coupling insert for quick-disconnect fluid connections. Its 3/8" hose barb accommodates flexible hose with a nominal 3/8" internal diameter, while the elbow configuration helps route tubing in confined equipment spaces.

Manufactured from acetal, this PLC-series insert features a Buna-N seal and 316 stainless steel valve spring. CPC specifies a pressure range from vacuum to 120 PSI and a temperature range of −40°C to +82°C.

Main Features:

  • Valved insert: Shuts off flow on the insert side when disconnected.
  • Elbow configuration: Supports compact hose routing.
  • 3/8" hose barb: Fits compatible 3/8" ID flexible hose.
  • Acetal construction: Lightweight polymer body.
  • Quick-disconnect interface: Requires a compatible mating coupling body.

Main Specifications:

Parameter

Details

NESPL product code

NSSP006662

Manufacturer

CPC / Colder Products Company

Manufacturer part number

PLCD23006

Series

PLC

Component type

Valved coupling insert

Configuration

Elbow

Hose termination

3/8" hose barb

Compatible hose ID

Approximately 9.5 mm

Body material

Acetal

Colour / finish

White / natural

Seal material

Buna-N / NBR

Valve spring

316 Stainless Steel

Pressure range

Vacuum to 120 PSI / 8.3 bar

Temperature range

−40°F to +180°F / −40°C to +82°C

Mounting option

Free-floating

Main Applications:

Subject to material and system compatibility:

  • Equipment fluid-transfer lines.
  • Water-handling assemblies.
  • Laboratory tubing systems.
  • Cooling and circulation equipment.
  • Service connections requiring regular disconnection.
Read More

Medical (Core) & Thermal Industry

Additional Information

NESPL Code NSSP006662
Manufacturer Code PLCD23006VMBLK
Manufacturer CPC Quick Connect & Disconnect Solutions
Type Quick Fittings
