PEP® Condenser Fan Motor
#NIDECNESPL30
Product Description
PEP® Condenser Fan Motor
High Efficiency PSC Motors for Condenser Fan Applications
Main Features:
- Residential and commercial condensing unit fan motors to
meet manufacturer's requirements.
- Up to 78% efficient, saving up to 70 watts.
- Hubless lead end.
- Drain holes on both ends.
- TEAO
Main Applications:
- Residential and commercial condensing unit fan motors to
meet manufacturer's requirements.
Main Specifications:
|
Agency Certification |
UL & CSA |
|
Ambient
Operating Temp. (Celsius) |
70 |
|
Bearing Type |
Ball |
|
Diameter |
5-5/8" |
|
Efficiency |
76% |
|
Enclosure |
TEAO |
|
F/L Amps |
7.50 |
|
HP |
1/2 |
|
Hz |
60/50 |
|
Insulation
Class |
F |
|
Mounting |
Band/Stud |
|
NEMA
Frame |
48Y |
|
Phase |
1 |
|
RPM |
1075 |
|
Rot. |
Rev. |
|
Service
Factor |
1.00 |
|
Shaft Diam. |
1/2" |
|
Shaft
Length |
5" |
|
Speeds |
1 |
|
Std.
Mount. Pos. |
All
Angle |
|
Thermal Protection |
Auto |
|
Type |
PSC |
|
Volts |
208-230 |
|
Wt.
Lbs. |
18.0 |
|
Shipping Weight |
19.10 |
|
Shipping
Width |
7.24 |
|
Shipping Length |
15.43 |
|
Shipping
Height |
7.24 |
Click to download : PDS_PEP_Heat PumpVarious Industry Products
Additional Information
| NESPL Code | NIDECNESPL30 |
| Manufacturer | Nidec |
| Type | Pump / Motor |
