The Fluid-o-Tech PA204F (PA0204FNADN0000) is a professional flange-mounted rotary vane pump designed to provide reliable water delivery and pressure generation in commercial equipment.

The pump has a nominal flow capacity of 200 litres per hour and features a durable brass pump body, 3/8" NPT connections, integrated bypass and 3-hole flange mounting system. These specifications are directly associated with the PA0204FNADN0000 / PA204F configuration.

Its positive-displacement rotary vane design makes it particularly suitable for applications where controlled water flow and consistent pressure are required. The compact flange-mounted construction allows the pump head to be coupled to a compatible electric motor.

Main Features:

• ⚙️ Rotary Vane Technology – Positive-displacement pumping principle for consistent liquid delivery.
• 💧 200 L/h Flow Rate – Designed for controlled water delivery in professional equipment.
• 🔩 3-Hole Flange Mount – Allows secure coupling with a compatible motor assembly.
• 🟡 Brass Pump Body – Robust construction for compatible water-handling applications.
• 🔗 3/8" NPT Connections – Threaded inlet and outlet connection configuration.
• 🔄 Integrated Bypass – PA0204FNADN0000 is documented as a bypass-equipped pump configuration.
• 📐 Compact Construction – Approximate pump-head length of 82 mm.
• ☕ Coffee Equipment Application – Widely documented for professional espresso and coffee-machine applications.

Main Specifications:

The technical specifications above are independently corroborated by REPA/GEV and other commercial parts references for PA0204FNADN0000 / PA204F.

Main Applications:

The PA204F is particularly suitable for compatible:

• ☕ Professional espresso machines
• ☕ Commercial coffee machines
• 💧 Pressurized water delivery systems
• 🥤 Beverage preparation equipment
• 🚰 Water circulation and transfer systems
• ⚙️ OEM fluid-handling equipment
• 🏨 Commercial foodservice equipment

Published compatibility data specifically identifies the PA204F for professional coffee-machine applications.

How It Works?

The PA204F uses a rotor containing sliding vanes. As the rotor turns, these vanes create expanding chambers at the inlet side, drawing water into the pump.

The trapped liquid is then carried around the pumping chamber. As chamber volume decreases near the outlet, the liquid is discharged under pressure.

This positive-displacement operation makes rotary vane pumps well suited to equipment requiring controlled flow combined with pressure generation.

Main Benefits:

·       Consistent Water Delivery: The 200 L/h pump capacity provides controlled water supply for compatible commercial equipment.

·       Pressure Generation: Rotary vane technology enables the pump to move water effectively against system resistance.

·       Compact Motor Integration: Its 3-hole flange mounting allows the pump head to be directly integrated with a compatible motor.

·       Durable Construction: Brass construction provides a robust solution for professional water-handling equipment.

·       Integrated Bypass: The bypass-equipped configuration helps suit the pump to pressurized fluid systems.

Compatibility

Published parts references associate PA0204FNADN0000 / PA204F with professional coffee equipment, including certain Faema DUE, E91, E92, E97, E98 and SMART machines. Compatibility should always be confirmed using the equipment model and original pump part number before ordering.

Installation & Replacement Note

Before replacing an existing pump with PA0204FNADN0000, verify the complete part number as well as:

• 3-hole flange configuration
• 3/8" NPT inlet/outlet connection
• Motor and coupling compatibility
• Shaft/coupling dimensions
• Direction of rotation
• Required 200 L/h flow capacity
• Operating pressure
• Liquid compatibility
• Existing bypass configuration
