Tygon® LCF Tubing
#SGN14
Product Description
Tygon®
LCF Tubing
Tygon® LCF
is a specialized thermoplastic elastomer (TPE) tubing created by Saint-Gobain
Medical to fulfill the stringent demands of the medical sector. Designed for
both flexibility and durability, Tygon LCF boasts an exceptionally low
coefficient of friction (COF), making it suitable for applications that require
smooth, lubricated movement, such as endoscopes and fiber optic cables. In
contrast to conventional fluoropolymers, Tygon LCF can endure gamma
sterilization without losing its mechanical strength. Whether utilized in
tracheal insertion or urinary procedures, Tygon LCF tubing provides a soft,
flexible design that may enhance patient comfort—especially in minimally
invasive methods like Natural Orifice Transluminal Endoscopic Surgery
(N.O.T.E.S.), which accesses the peritoneal cavity through natural openings.
Main
Features:
- Economical
polymer with a low coefficient of friction.
- Retains
lubricating properties post gamma sterilization, in contrast to PTFE.
- Designed
for both flexibility and durability.
Main
Specifications:
|
Property |
ASTM Method |
Value or Rating |
|
Durometer Hardness (Shore A) |
D2240 |
72 |
|
Tensile Strength, psi
(Mpa) |
D412 |
2710 (18.68) |
|
Ultimate Elongation, % |
D412 |
810 |
|
Tear Resistance,
lbs-f/in (kN/m) |
D1004 |
270 (.03) |
|
Compression Set |
D395 |
17 |
|
Specific Gravity |
D792 |
0.90 |
|
Maximum Recommended Operating Temperature °F
(°C) |
N/A |
100 (38) |
Medical (Core) & Thermal Industry
Additional Information
| NESPL Code | SGN14 |
| Manufacturer Code | Tygon® LCF |
| Manufacturer | Saint Gobain |
| Type | Medical Tubing |
