W11542868 Ice Maker Reservoir Drain Pump

W11542868 Ice Maker Reservoir Drain Pump | Ice Machine Replacement Pump

The W11542868 Ice Maker Reservoir Drain Pump is a replacement pump assembly designed for compatible commercial and built-in ice makers. Its primary function is to remove water from the ice machine reservoir during the drain or reservoir-flushing process, helping the machine discharge water containing accumulated impurities and prepare the water system for continued operation.

During operation, water remaining in the reservoir must periodically be discharged. The W11542868 pump moves this water from the reservoir into the machine's drainage path. Proper drainage helps prevent unwanted water accumulation and supports the normal operating and cleaning cycles of the ice maker.

This pump is used across a range of compatible Whirlpool, KitchenAid and Jenn-Air ice machines, with additional cross-brand applications reported for certain models. Exact compatibility should always be verified using the equipment model and existing part number before ordering.

Main Features:

• 💧 Reservoir Drain Function – Pumps water out of the ice maker reservoir during the required drain/flush cycle.
• 🧊 Designed for Ice Makers – Specifically used as an ice-machine reservoir drain pump.
• 🔄 Supports Reservoir Flushing – Helps discharge water when the reservoir is flushed to remove accumulated impurities.
• ⚙️ Pump Assembly – Complete replacement pump assembly for compatible equipment.
• 🔧 Service Replacement Part – Suitable for replacing a worn, failed, blocked or non-operational reservoir drain pump.
• 💦 Helps Prevent Water Accumulation – Proper pump operation allows water to leave the reservoir through the intended drainage system.
• 🛠️ Direct Replacement Application – Designed to replace several earlier pump numbers.
• 🏪 Suitable for Commercial Applications – Used in compatible built-in and commercial-style ice-making equipment.

Main Specifications:

Replaces / Cross-References

W11542868 replaces the following earlier part numbers:

• W11439192
• W10489125
• WPW10489125

These supersessions are listed by Whirlpool replacement-parts sources and Sears Parts Direct.

How W11542868 Works?

During the appropriate drain or flushing stage of the ice maker's operating cycle:

Water collects in reservoir → Drain pump activates → Water is pumped from reservoir → Water travels through drainage path → Reservoir is cleared for continued operation

This is particularly important during reservoir flushing because the machine needs to remove water carrying impurities rather than continually retaining it within the water system. Sears' parts documentation specifically describes W11542868 as removing reservoir water when the reservoir is flushed to remove impurities.

Important: Drain Pump vs. Circulation Pump

This distinction is important for your NESPL website because W11542867 and W11542868 are two different pumps.

Parts listings for the same machines show both components separately, confirming that W11542868 should not be described as the primary water circulation pump.

Therefore, I recommend using “Ice Maker Reservoir Drain Pump” rather than simply “Water Pump” in your H1/product title.

Compatible Equipment

W11542868 is documented for multiple ice-machine models. Examples found in verified parts listings include:

• KitchenAid KUIC15POZP1
• KitchenAid KUIX305ESS2
• KitchenAid KUID508HPS00
• KitchenAid KUIX305EBL0
• Whirlpool WUI75X15HB00

Published parts information also associates W11542868 with Whirlpool, KitchenAid, Jenn-Air, Maytag and other related applications, depending on the exact equipment model.

Common Symptoms of a Faulty Drain Pump

Inspection or replacement of the W11542868 may be required when the machine experiences:

• Water remaining in the reservoir when it should drain
• Poor or incomplete reservoir drainage
• Water pooling inside the machine
• Drain cycle not completing normally
• Unusual pump noise during drainage
• Pump motor operating intermittently or not operating
• Ice-making cycle interruption associated with drainage
• Water not being expelled during reservoir flushing

These symptoms can also be caused by blocked tubing, drainage restrictions, electrical problems or other components, so diagnosis is recommended before replacing the pump.

Main Applications:

Suitable for compatible ice-making equipment used in:

• Restaurants
• Cafés
• Hotels
• Bars
• Commercial kitchens
• Beverage service areas
• Hospitality facilities
• Offices and institutional facilities
• Residential premium/built-in ice makers
• Foodservice operations

Installation & Replacement

Installation should preferably be carried out by a qualified appliance or refrigeration service technician.

Before installation:

1. Disconnect the ice maker from electrical power.
2. Shut off the water supply where required.
3. Access the existing reservoir drain pump.
4. Inspect the drain tubing and connections for blockage.
5. Disconnect the existing pump connections.
6. Install W11542868 in the correct position.
7. Reconnect tubing and electrical connections securely.
8. Restore power/water and test the machine through a complete operating and drain cycle.
9. Inspect the connections for leakage.

Sears specifically instructs users to disconnect power before installation and recommends protective gloves during replacement.
