Manitowoc Ice 000009122 Water Inlet Valve Kit – 230V, 50/60Hz, 6W

The Manitowoc Ice 000009122 Water Inlet Valve Kit is a replacement water-control assembly designed for compatible commercial ice machines. Its primary function is to control the incoming water supply to the ice machine, opening when energized to allow water into the machine and closing when the required water-fill operation is complete. Manitowoc's own service documentation identifies 000009122 as the 230V Water Inlet Valve.

Proper operation of the inlet valve is important for maintaining the required water supply during the ice-making process. A worn, blocked, leaking or electrically failed inlet valve can contribute to insufficient filling, continuous water flow, leakage or inconsistent ice production.

Main Features

• 💧 Automatic Water Inlet Control – Regulates incoming water flow during the ice machine's operating cycle.
• ⚡ 230V Operation – Designed for compatible 230V electrical systems.
• 🔌 50/60Hz Frequency – Suitable for compatible 50Hz and 60Hz applications.
• ⚙️ 6W Power Rating – The valve coil is specified at 6 watts.
• 🧊 Designed for Commercial Ice Machines – Used across compatible S-Series, Indigo and selected Koolaire equipment.
• 🔄 Electrically Operated Solenoid Valve – Opens the water passage when the coil is energized and closes it when power is removed.
• 🛠️ Replacement Kit Configuration – Supplied with components required for installation on applicable machines.
• 📦 Complete Kit – Listed kit contents include 1 inlet valve, 4 screws, 1 inlet tube and 2 support brackets.
• 🔧 Service Replacement Part – Manitowoc provides dedicated installation instructions covering kit 000009122 and related inlet-valve kits.

Technical Specifications

The electrical specifications above are supported by current parts documentation, while Manitowoc's own truck-box/service documentation explicitly identifies 000009122 as its 230V Water Inlet Valve.

Kit Includes

The standard 000009122 kit is listed with:

• 1 × Water Inlet Valve
• 4 × Screws
• 1 × Inlet Tube
• 2 × Support Brackets

Manitowoc's installation instructions show that installation can involve the new valve, service bracket, clear vinyl tubing and reconnection of the electrical plug to the valve coil.

How the Water Inlet Valve Works

During the machine's water-fill sequence, the control system supplies electrical power to the 000009122 valve coil. The energized valve opens the water passage and allows incoming water to enter the machine.

When the required fill sequence is completed, power to the valve is removed and the valve closes, stopping the incoming water supply. This controlled filling process helps ensure that the ice machine receives the water needed for proper ice production.

Common Symptoms of a Faulty Water Inlet Valve

Inspection or replacement of the inlet valve may be required if the compatible ice machine experiences:

• Insufficient or no water entering the machine
• Valve failing to open when energized
• Continuous water filling
• Water leakage around the valve
• Valve remaining stuck open
• Irregular water supply during the ice-making cycle
• Reduced or inconsistent ice production

A Manitowoc parts/service source specifically identifies a valve stuck open, leakage around the coil, and failure to open when voltage is supplied as common reasons for replacement.

Compatibility

The 000009122 is used on numerous compatible commercial ice-machine configurations. Parts documentation lists applications across S-Series, Indigo and selected Koolaire machines, while Manitowoc's installation instructions cover S-model and other applicable configurations.
