12556950081 BSPT Male Elbow Hose Connector

#NESPLTEFEN23

Product Description

The Tefen part 12356805081 NPT Male Hose Connector is a straight barb to thread adaptor designed for a 5/16 tube outer diameter hose and a 1/2 NPT male thread. Built for robust performance, it features a length of 51.0 mm and 22 mm wrench flat width. Suitable for demanding fluid systems, it supports up to 14 bar (200psi) at 20 °C and typically operates across –20°C to +120 °C when made in PVDF.

Main Features:

Connection type: Hose barb fit (5/16 tube ID) on one side and male NPT thread (½) on the other.
Material & construction: Typically made from PVDF (or similar high performance plastic) offering strong chemical resistance.
Working pressure: Rated up to 14 bar (200psi) at 20 °C.
Operating temperature range: Suitable for 20°C up to +120 °C (subject to application and media).
Compact design & size: With overall length ~51.0 mm and wrench flat across width ~22 mm for ease of installation in tight installations.

Main Specifications:

Unit type	Metric
Material	PVDF
Thread Type	BSPT
Color	White
L mm	45.5
L1 mm	37.8
M BSPT	1/2
Tube ID mm	10
Inner Diameter	10
Temperature Range	-20°C up to +120°C
Working Pressure	Up to 14 bar (200 psi) at +20° C
