12356805081 NPT Male Hose Connector

#NESPLTEFEN22

Product Description

12356805081 NPT Male Hose Connector

The Tefen part 12356805081 NPT Male Hose Connector is a straight barb to thread adaptor designed for a 5/16 tube outer diameter hose and a 1/2 NPT male thread. Built for robust performance, it features a length of 51.0mm and 22mm wrench flat width. Suitable for demanding fluid systems, it supports up to 14 bar (200 psi) at 20 °C and typically operates across –20 °C to +120 °C when made in PVDF.

Main Features:

Connection type: Hose barb fit (5/16 tube ID) on one side and male NPT thread (½) on the other.

Material & construction: Typically made from PVDF (or similar high performance plastic) offering strong chemical resistance.

Working pressure: Rated up to 14 bar ( 200psi) at 20 °C.

Operating temperature range: Suitable for 20?°C up to +120 °C (subject to application and media).

Compact design & size: With overall length ~51.0 mm and wrench?flat across width ~22 mm for ease of installation in tight installations.

Main Specifications:

Unit type	Imperial
Material	PVDF
Thread Type	NPT
Color	White
L mm	51
SW mm	22
M NPT	1/2
Tube ID inch	5/16
Inner Diameter	5/16
Temperature Range	-20°C up to +120°C
Working Pressure	Up to 14 bar (200 psi) at +20° C
